| MOQ: | 1 |
| Price: | 45000-120000usd |
| Standard Packaging: | Wooden case packing |
| Delivery Period: | 15-30days |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Capacity: | 20 Set/Sets per Month |
Semi Automatic Milk Powder Food Can Production Line
Features:
1. PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.
2. Low voltage apparatus are produced by SCHNEIDER.
3. IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.
4. OMRON is our sensor supplier.
5. HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.
| Coating and drying machine | |
| Transmission Speed | 6-24m/min |
| Capacity | 80 cans/min |
| Applicable Can Diameter | Φ73-Φ176mm |
| Applicable Can Height | 100-250mm |
| Applicable Can Body Thickness | 0.15-0.35mm |
| Drying Room | 8pcs |
| Power | 16KW |
| Weight | 2000kgs |
| Dimensions | 1300*200*160mm |
| Flanging machine | |
| Productivity | 60~80 cans/ min |
| Model | GT3B2(3B5) Flanging machine |
| Applied can’s drive | diameter 40~180mm |
| Power consumption | 1.1kw |
| Size | 1200×670×1500mm |
| Weight | 900kg |
| Sealing machine | ||||
| Model: | GT4B2B | |||
| Capacity: | 42cans/min | |||
| Diameter: | 52-105mm | |||
| Maximum Height: | 52-280mm | |||
| Power: | 1.5kw | |||
| Net weight: | 1200kgs | |||
| Dimension: | 1210×1460×1900mm | |||
| Beading machine | ||||
| Model: | GT3B27 | |||
| Capacity: | 15-35cans/min | |||
| Diameter: | 73-153mm | |||
| Height: | 124-189mm | |||
| Power: | (speed regulating motor)2.2kw | |||
| Net Weight: | 800kgs | |||
| Dimension: | 1570x980x1140mm | |||
1. Q: How does your factory do regarding quality control?
A: We have passed the ISO9001:2000 Quality Management System and CE certifate and we have a special QC department in charge of products' quality.
2. Q: How long is the warranty period?
A: Normally one year warranty,
3. Q: What's the main market of your company?
A: Our products are well sold throughout the country and exported to many different countries, such as, Southeast Asia, Russia, Europe, Middle East, Africa, America and etc.
4. Q: How much production capacity of your company one year?
A: This depends on your needs.
5. Q: Can we visit your machine operation in your factory?
A: Yes, we will test the machine before shipment, welcome to visit our factory to see the operation.
Packing and Shipping:
The Automatic Tin Can Making Machine will be packaged in a wooden crate, ensuring that the machine arrives in perfect condition. The crate will then be shipped to the customer's address, using a reliable and secure shipping service.
After-sale Service:
24 hours online service,engineers available to service machinery overseas,online support,video technical support,field installation.
|
|
